ideo/Audio Input |
|
IP video input: |
| |
128-ch |
|
Two-way audio input: |
| |
1-ch, RCA (2.0 Vp-p, 1kΩ) |
|
Network |
|
Incoming bandwidth: |
| |
400Mbps |
|
Outgoing bandwidth: |
| |
400Mbps |
|
Remote connection: |
| |
256 |
|
Video/Audio Output |
|
HDMI Output: |
| |
2-ch
HDMI 1 supports 64-window division, and HDMI 2 supports 16-window division. |
|
LCD/HDMI/VGA output resolution: |
| |
1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz,
1280 × 720 /60Hz, 1024 × 768 /60Hz |
|
Recording Resolution: |
| |
8MP/6MP/5MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
|
Audio Output: |
| |
1-ch, RCA (2.0Vp-p, 1KΩ) |
|
VGA Output: |
| |
1-ch |
|
Decoding |
|
Live view / Playback: |
| |
8MP/6MP/5MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
|
Capability: |
| |
8-ch@1080P |
|
Hard Disk |
|
SATA: |
| |
16 SATA interfaces for 16 HDDs |
|
miniSAS (Optional): |
| |
1 miniSAS interface |
|
Capacity: |
| |
Up to 6TB capacity for each HDD |
|
Disk array |
|
Array type: |
| |
RAID0, RAID1, RAID5, RAID10 |
|
External Interface |
|
Optic fiber interface: |
| |
4 1000 Mbps optic fiber interfaces |
|
Network Interface: |
| |
4 RJ-45 10 /100 /1000 Mbps self-adaptive Ethernet interfaces |
|
Serial Interface: |
| |
RS-232, RS-485, Keyboard |
|
USB Interface: |
| |
Front panel: 2 × USB 2.0
Rear panel: 2 × USB 3.0 |
|
Alarm In: |
| |
16-ch |
|
Alarm Out: |
| |
8-ch |
|
General |
|
Power Supply: |
| |
100 ~ 240 VAC, 6.3 A, 50 ~ 60 Hz |
|
Consumption(without hard disk and POE): |
| |
≤ 100 W |
|
Working Temperature: |
| |
-10 ºC ~ +55 ºC (+14 ºF~ + 131 ºF) |
|
Working Humidity: |
| |
10 % ~ 90 % |
|
Chassis: |
| |
19-inch rack-mounted 3U chassis |
|
Dimensions: |
| |
442 × 494 ×146 mm (17.4″ ×19.4″× 5.7″) |
|
Weight(without HDD): |
| |
≤ 15.5 Kg (34.2 lb) |
